VLV32 type 0.6/1KV PVC Insulated Power Cable
Classification:
Product Description
Low Voltage(0.6/1KV) Power Cable-VLV32
VLV32 PVC armored power cable is a high-performance, armored aluminum conductor cable designed for efficient and secure power transmission. Engineered for global industrial and utility applications, this cable ensures outstanding electrical performance, mechanical strength, and long-term durability in harsh environments. The VLV32 PVC armored power cable is particularly well-suited for underground installations, offering excellent protection against mechanical stress and external damages.
Standard
IEC 60228 Conductors of Insulate Cables
IEC 60502-1 Power Cables with Extruded Insulation and Their Accessories for Rated Voltages from 1kV(Um=1.2kV) up to 30kV(Um=36kV) - Part 1: Cables for Rated Voltages of 1kV (Um=1.2kV) and 3kV(Um=3.6kV)
Features
Voltage Rating: 6kV to 35kV
Conductor Material: High-purity stranded aluminum
Insulation Material: Cross-linked polyethylene (XLPE) for superior electrical performance
Armor: Steel Tape Armored (STA) for mechanical reinforcement
Outer Sheath: PVC or PE jacket for enhanced durability
Temperature Resistance: Operates within -15°C to +90°C
Short Circuit Tolerance: Withstands short circuit temperatures up to 250°C for 5 seconds
Construction
● Conductor: Aluminum, class 1 or class 2, solid or stranded, circular or circular compacted conductors
● Insulation: Polyvinyl chloride PVC
● Filler: Non-hygroscopic material
● Binder: Non-hygroscopic material
● Inner sheath: Polyvinyl chloride PVC
● Armour: Steel wire
● Binder: Non-hygroscopic material
● Outer sheath: Polyvinyl chloride PVC
Application
Civil buildings and commercial facilities: provide safe and reliable power connections for homes, office buildings and commercial centers;
Industrial automation and control systems: meet the precise transmission requirements of industrial equipment and automation control systems;
Low-voltage power distribution system: suitable for cable laying of low-voltage systems such as distribution boxes and control cabinets;
Municipal engineering: covers power wiring of roads, bridges and public facilities to ensure long-term safe operation.
Product structure and parameter
No. of Cores and Nominal Cross Section | Min. Number of Wires | Nominal Insulation Thickness | Nominal | Nominal | Approx. | Approx. Weight | Max. D.C. Resistance of Conductor |
No. × mm² | No. | mm | mm | mm | mm | kg/km | Ω/km |
2×2.5 | 1 | 0.8 | 0.8 | 1.8 | 14.5 | 338 | 12.1 |
2×4 | 1 | 1.0 | 0.8 | 1.8 | 16.3 | 415 | 7.41 |
2×6 | 1 | 1.0 | 1.25 | 1.8 | 18.2 | 592 | 4.61 |
2×10 | 6 | 1.0 | 1.25 | 1.8 | 20.7 | 697 | 3.08 |
2×16 | 6 | 1.0 | 1.25 | 1.8 | 22.3 | 827 | 1.91 |
2×25 | 6 | 1.2 | 1.6 | 1.8 | 26.2 | 1194 | 1.20 |
2×35 | 6 | 1.2 | 1.6 | 1.8 | 28.2 | 1366 | 0.868 |
3×2.5 | 1 | 0.8 | 0.8 | 1.8 | 15.1 | 368 | 12.1 |
3×4 | 1 | 1.0 | 0.8 | 1.8 | 16.9 | 456 | 7.41 |
3×6 | 1 | 1.0 | 1.25 | 1.8 | 18.9 | 643 | 4.61 |
3×10 | 6 | 1.0 | 1.25 | 1.8 | 21.7 | 783 | 3.08 |
3×16 | 6 | 1.0 | 1.25 | 1.8 | 23.4 | 934 | 1.91 |
3×25 | 6 | 1.2 | 1.6 | 1.8 | 27.5 | 1341 | 1.20 |
4×2.5 | 1 | 0.8 | 0.8 | 1.8 | 15.9 | 410 | 12.1 |
4×4 | 1 | 1.0 | 1.25 | 1.8 | 18.9 | 641 | 7.41 |
4×6 | 1 | 1.0 | 1.25 | 1.8 | 20.2 | 726 | 4.61 |
4×10 | 6 | 1.0 | 1.25 | 1.8 | 23.2 | 885 | 3.08 |
4×16 | 6 | 1.0 | 1.6 | 1.8 | 25.9 | 1213 | 1.91 |
4×25 | 6 | 1.2 | 1.6 | 1.8 | 29.7 | 1549 | 1.20 |
5×2.5 | 1 | 0.8 | 0.8 | 1.8 | 16.9 | 458 | 12.1 |
5×4 | 1 | 1.0 | 1.25 | 1.8 | 20.1 | 717 | 7.41 |
5×6 | 1 | 1.0 | 1.25 | 1.8 | 21.5 | 823 | 4.61 |
5×10 | 6 | 1.0 | 1.6 | 1.8 | 25.6 | 1147 | 3.08 |
5×16 | 6 | 1.0 | 1.6 | 1.8 | 27.8 | 1382 | 1.91 |
5×25 | 6 | 1.2 | 1.6 | 1.9 | 32.3 | 1798 | 1.20 |
3×4+1×2.5 | 1/1 | 1.0/0.8 | 1.25 | 1.8 | 18.4 | 612 | 7.41/12.1 |
3×6+1×4 | 1/1 | 1.0/1.0 | 1.25 | 1.8 | 19.9 | 712 | 4.61/7.41 |
3×10+1×6 | 6/1 | 1.0/1.0 | 1.25 | 1.8 | 22.5 | 850 | 3.08/4.61 |
3×16+1×10 | 6/6 | 1.0/1.0 | 1.6 | 1.8 | 25.4 | 1164 | 1.91/3.08 |
3×25+1×16 | 6/6 | 1.2/1.0 | 1.6 | 1.8 | 28.8 | 1476 | 1.20/1.91 |
4×4+1×2.5 | 1/1 | 1.0/0.8 | 1.25 | 1.8 | 19.7 | 689 | 7.41/12.1 |
4×6+1×4 | 1/1 | 1.0/1.0 | 1.25 | 1.8 | 21.2 | 799 | 4.61/7.41 |
4×10+1×6 | 6/1 | 1.0/1.0 | 1.6 | 1.8 | 24.9 | 1106 | 3.08/4.61 |
4×16+1×10 | 6/6 | 1.0/1.0 | 1.6 | 1.8 | 27.3 | 1335 | 1.91/3.08 |
4×25+1×16 | 6/6 | 1.2/1.0 | 1.6 | 1.9 | 31.4 | 1709 | 1.20/1.91 |
4×35+1×16 | 6/6 | 1.2/1.0 | 1.6 | 1.9 | 33.6 | 1943 | 0.868/1.91 |
